B–63175EN/03

2. HARDWARE

119

The Power Mate i has the following LEDs and switches.

LEDM1 displays the status information of the Power Mate. It is used

along with the MTSW rotary switch and PSW pushbutton switch also to

control setting and maintenance operations.

LEDM2 is used to indicate that the 24 VDC input power fuse in the

control unit has blown. See Section 2.7.1 for how to replace the fuse.

MTSW is a rotary switch used along with the LEDM1 7–segment LED

indicator and the PSW pushbutton switch for setting and maintenance

operations. Normally, set the switch to the 0 position.

PSW is a pushbutton switch used along with the LEDM1 7–segment LED

indicator and the PSW pushbutton switch for setting and maintenance

operations.

NOTE

For details on the LEDM1, MTSW, and PSW, see

“SETTING/DISPLAY/MAINTENANCE USING THE MAIN

UNIT OF THE Power Mate i,” in Appendix F.

2.2.3

LEDs and Switches on

the Control Units

D 7–segment LED (LEDM1)

D Blown fuse indication

LED (LEDM2)

D Rotary switch (MTSW)

D Pushbutton switch

(PSW)
