G. ALARM LIST
991
Number ContentsMessage
5199 FINE TORQUE SENSING PARAME-
TER
A parameter related to the fine torque sensing function is illegal.
· The storage interval is invalid.
· An invalid axis number is set as the target axis.
Correct the parameter.
5212 SCREEN COPY : PARAMETER ER-
ROR
There is a parameter setting error. Check that 4 is set as the I/O channel.
5213 SCREEN COPY : COMMUNICA-
TION ERROR
The memory card cannot be used. Check the memory card. (Check
whether the memory card is write–protected or defective.)
5214 SCREEN COPY : DATA TRANSFER
ERROR
Data transfer to the memory card failed.
Check whether the memory card space is insufficient and whether the
memory card was removed during data transfer.
5218 ILLEGAL PARAMETER (INCL.
COMP)
There is an inclination compensation parameter setting error.
Cause:
1. The number of pitch error compensation points between the nega-
tive (–) end and positive (+) end exceeds 128.
2. The relationship in magnitude among the inclination compensation
point numbers is incorrect.
3. An inclination compensation point is not located between the nega-
tive (–) end and positive (+) end of the pitch error compensation
points.
4. The amount of compensation per compensation point is too large or
too small.
Correct the parameter.
5220 REFERENCE POINT ADJUST-
MENT MODE
A parameter for automatically set a reference position is set. (Bit 2 of
parameter No. 1819 = 1)
Perform automatic setting.
(Position the machine at the reference position manually, then perform
manual reference position return.)
Supplementary: Automatic setting sets bit 2 of parameter No. 1819 to
0.
5222 SRAM CORRECTABLE ERROR The SRAM correctable error cannot be corrected.
Cause:
A memory problem occurred during memory initialization.
Action:
Replace the master printed circuit board (SRAM module).
5227 FILE NOT FOUND A specified file is not found during communication with the built–in
Handy File.
5228 SAME NAME USED There are duplicate file names in the built–in Handy File.
5229 WRITE PROTECTED A floppy disk in the built–in Handy File is write protected.
5231 TOO MANY FILES The number of files exceeds the limit during communication with the
built–in Handy File.
5232 DATA OVER–FLOW There is not enough floppy disk space in the built–in Handy File.
5235 COMMUNICATION ERROR A communication error occurred during communication with the built–in
Handy File.
5237 READ ERROR A floppy disk in the built–in Handy File cannot be read from. The floppy
disk may be defective, or the head may be dirty. Alternatively, the Handy
File is defective.
5238 WRITE ERROR A floppy disk in the built–in Handy File cannot be written to. The floppy
disk may be defective, or the head may be dirty. Alternatively, the Handy
File is defective.
