OPERATION11. SETTING AND DISPLAYING DATA B–63014EN/02

812

ACTUAL POSITION O1000 N10010

100.000

200.000

300.000

(ACTUAL SPEED) F : 0MM/MIN

S : 0RPM

(PARTS COUNT) 114

(RUN TIME) 5H 3M

(CYCLE TIME) 0H 0M 6S

ABS

REL (OPRT)

O2000 N20010

400.000

500.000

600.000

ALL HNDL

D Display with two–path control)

(9.5″/10.4″LCD)

(RELATIVE)

(ACTUAL SPEED) F : 0MM/MIN

S : 0RPM

(PARTS COUNT) 114

(RUN TIME) 5H 3M

(CYCLE TIME) 0H 0M 6S

MEM STOP *** *** 12:34:56 HEAD1

The current position of the tool in the relative coordinate system can be

reset to 0 or preset to a specified value as follows:

Procedure to set the axis coordinate to a specified value

1 Enter an axis address (such as X or Y) on the screen for the relative

coordinates. The indication for the specified axis blinks and the soft

keys change as shown on the left.

2 ⋅ To reset the coordinate to 0, press soft key

[ORGIN]. The relative

coordinate for the blinking axis is reset to 0.

⋅ To preset the coordinate to a specified value, enter the value and

press soft key

[PRESET]. The relative coordinate for the blinking

axis is set to the entered value.

Procedure to reset all axes

1 Press soft key [(OPRT)].

2 Press soft key

[ORIGIN].

3 Press soft key

[ALLEXE].

The relative coordinates for all axes are reset to 0.

Explanations

D Setting the relative

coordinates

Procedure

ORIGIN

246.912

Y 913.780

Z 578.246

MEM

PRESET

Procedure

ORIGIN

EXEC

RELABS

ALL

(OPRT)

ALLEXE
