OPERATION3. MANUAL OPERATION
B–63014EN/02
604
Example 2: When the maximum number of controlled axes is 7 or 8
PRGRM
PROGRAM (JOG) O0010 N00020
JOG
*
* * * * * * * * *
00 : 00 : 00
G00 P (ABSOLUTE) (DISTANCE TO GO)
X X 0.000 X 0.000
Y Y 0.000 Y 0.000
Z Z 0.000 Z 0.000
U U 0.000 U 0.000
V V 0.000 V 0.000
W W 0.000 W 0.000
A A 0.000 A 0.000
C C 0.000 C 0.000
MT
SB
>_
JOG CURRNT (OPRT)NEXT
4 Enter the required commands by using address keys and numeric keys
on the MDI panel, then press soft key [INPUT] or the
INPUT
key to set
the entered data.
PROGRAM (JOG) O0010 N00020
JOG
*
* * * * * * * * *
00 : 00 : 00
G00 P (ABSOLUTE) (DISTANCE TO GO)
X 10.000 X 0.000 X 0.000
Y Y 0.000 Y 0.000
Z Z 0.000 Z 0.000
U U 0.000 U 0.000
V V 0.000 V 0.000
W W 0.000 W 0.000
M
S
T
B
>Z120.5_
CLEAR INPUT
The following data can be set:
1. G00: Positioning
2. G01: Linear interpolation
3. G28: Automatic reference position return
4. G30: 2nd/3rd/4th reference position return
5. M codes: Miscellaneous functions
6. S codes: Spindle functions
7. T codes: Tool functions
8. B codes: Second auxiliary functions
The set data is maintained even when the screen or mode is changed.
