Series 16i/18i/160i/180i/160is/180is - MA Operators manual Page 628

Operators manual

Page of 1111

/ 1111

OPERATION3. MANUAL OPERATION

B–63014EN/02

608

After address B, specify a numeric value of no more than the number of

digits specified by parameter No. 3033.

NOTE

1 B codes can be renamed ”U,” ”V,” ”W,” ”A,” or ”C” by setting

parameter No. 3460. If the new name is the same as an axis

name address, ”B” is used. When ”B” is used, and axis

name ”B” exists, ”B” is used as the axis address. In this

case, no second auxiliary function can be specified.

2 Subprogram calls cannot be performed using B codes.

(1)When addresses and numeric values of a command are typed, then soft

key

[INPUT] is pressed, the entered data is set. In this case, the input

unit is either the least input increment or calculator–type input format,

according to the setting of bit 0 (DPI) of parameter No. 3401.

The

INPUT

key on the MDI panel can be used instead of soft key

[INPUT].

(2)Commands can be typed successively.

(3)Key entry is disabled during execution.

If soft key [INPUT] or the

INPUT

key on the MDI panel is pressed during

execution, an ”EXECUTION/MODE SWITCHING IN PROGRESS”

warning is output.

(4)If input data contains an error, the following warnings may appear:

Warning Description

FORMAT ERROR

⋅ A G code other than G00, G01, and G28 has been

entered.

⋅ An address other than those displayed on the manual

numeric command screen has been entered.

TOO MANY DIGITS

A value that exceeds the following limitations has been

entered.

⋅ Address G: 2 digits

⋅ Address P: 1 digit

⋅ Axis address: 8 digits

⋅ M, S, T, B: The parameter–set number of digits

NOTE

Even when the memory protection key is set, key input can

nevertheless be performed.

D B codes (second

auxiliary functions)

D Data input
