Series 16i/18i/160i/180i/160is/180is - MA Operators manual Page 896

Operators manual

Page of 1111

/ 1111

OPERATION

11. SETTING AND DISPLAYING DATA

B–63014EN/02

876

NOTE

Pressing the key resets the displayed T and M

addresses to 0. Once MEM or MDI mode has been

selected, however, the modal T and M codes are displayed.

RESET

4 Use the numeric keys to enter the distance from the base measurement

surface to the measurement surface, then press soft key

[HM INPUT]

to set the distance. For details of the measurement surface and base

measurement surface, see Explanations, below.

5 Select the tool for which the tool length offset value is to be measured.

While ”OFST” is blinking at the bottom of the tool length offset

measurement screen, a T code or M code can be specified in manual

handle feed or jog feed mode (manual numeric command). First,

enter Ttttt (where tttt is a T code number), then press the cycle start

button on the machine operator’s panel or MDI panel. The Ttttt

command is executed, thus selecting the tool to be measured. Then,

usually, enter the M06 command to move the tool to the spindle

position. Once the tool for which the tool length offset is to be

measured has been selected at the spindle position, position the cursor

to the tool offset number with which the tool length offset for the

selected tool is to be stored. The positioning of the cursor to the offset

number is usually done by the operator. Some machines, however,

automatically position the cursor to an appropriate tool offset number

upon the completion of tool selection, if bit 5 (QNI) of parameter No.

5005 is set to 1.

6 Perform manual handle feed or jog feed to move the tool until it

touches the measurement surface of the workpiece or reference block.

7 Press soft key

[MEASURE B]. The tool length offset is stored in the

tool offset memory. If tool offset memory B or C is being used, the

tool length offset is set as the tool geometry value, while 0 is set as the

tool wear offset. The cursor remains positioned to the set tool offset

number. To automatically advance the cursor to the next tool offset

number upon the completion of the setting an offset, press soft key

[MEASURE B+], instead of [MEASURE B].

8 Once the tool length offset has been set, the tool is automatically

moved to the tool change position.

9 This completes tool length offset measurement for a single tool. To

measure the tool length offsets of other tools, repeat steps 5 to 8.

10 Once the tool length offsets of all tools have been measured, set the

tool offset measurement mode switch on the machine operator’s

panel to OFF. The ”OFST” blinking indication is cleared from the

bottom of the screen.
