OPERATIONB–63014EN/02 9. EDITING PROGRAMS
785
For a 2–path control CNC, setting bit 0 (PCP) of parameter No. 3206 to
1 enables the copying of a specified machining program from one path to
another. Single–program copy and specified–range copy are supported.
Procedure for copying a program between two paths
1 Select EDIT mode for both paths.
2 Press function key
PROG
.
3 Press soft key
[(OPRT)].
4 Press soft key
[P COPY].
The following soft keys appear:
**** *** ***
O1357 N00130
PROGRAM
O1357 (HEAD–1 MAIN PROGRAM) ;
N010 G90 G00 X200.0 Z220.0 ;
N020 T0101 ;
N030 S30000 M03 ;
N040 G40 G00 X40.0 Z180.0 ;
N080 X100.0 Z80.0 ;
N090 Z60.0 ;
N100 X140.0 Z40.0 ;
>_
EDIT 14:25:36
CAN
PATH1 PATH2
HEAD1
5 Press soft key [PATH1] or [PATH2] to select the path from which a
program is to be copied.
(Example) Pressing soft key
[PATH1] causes an operation guidance,
shown below, to appear on the screen.
**** *** ***
SOURCE : PATH1 =1357
DEST : PATH2 = REPLACE : OFF
>_
EDIT 14:25:36
EXEC
SOURCE REPLACE
HEAD1
DEST CAN
⋅ First, the program currently selected for the copy source path is
displayed as the program to be copied. If no program has been
selected for the copy source path, ”0000” is displayed.
9.10
COPYING A
PROGRAM
BETWEEN TWO
PATHS
Procedure
