APPENDIX

B–63014EN/02

G. ALARM LIST

997

Number ContentsMessage

466 n AXIS : MOTOR/AMP COMBINA-

TION

The maximum current rating for the amplifier does not match that for

the motor.

467 n AXIS : ILLEGAL SETTING OF

AXIS

The servo function for the following has not been enabled when an

axis occupying a single DSP (corresponding to two ordinary axes) is

specified on the axis setting screen.

1. Learning control (bit 5 of parameter No. 2008 = 1)

2. High–speed current loop (bit 0 of parameter No. 2004 = 1)

3. High–speed interface axis (bit 4 of parameter No. 2005 = 1)

The details of servo alarm are displayed in the diagnosis display (No. 200

and No.204) as shown below.

OVL200

OVC

HCA

HVA

DCA

FBA

OFA

#7 (OVL) : An overload alarm is being generated.

#6 (LV) : A low voltage alarm is being generated in servo amp.

#5 (OVC) : A overcurrent alarm is being generated inside of digital servo.

#4 (HCA) : An abnormal current alarm is being generated in servo amp.

#3 (HVA) : An overvoltage alarm is being generated in servo amp.

#2 (DCA) : A regenerative discharge circuit alarm is being generated in servo amp.

#1 (FBA) : A disconnection alarm is being generated.

#0 (OFA) : An overflow alarm is being generated inside of digital servo.

ALD201

#6 #5 #4

EXP

#3 #2 #1 #0

When OVL equal 1 in diagnostic data No.200 (servo alarm No. 400 is

being generated):

#7 (ALD) 0 : Motor overheating

1 : Amplifier overheating

When FBAL equal 1 in diagnostic data No.200 (servo alarm No. 416 is

being generated):

ALD EXP Alarm details

1 0 Built–in pulse coder disconnection (hardware)

1 1 Separately installed pulse coder disconnection

(hardware)

0 0 Pulse coder is not connected due to software.

204

OFS

MCC

LDA

PMS

#2 #1 #0

#6 (OFS) : A current conversion error has occured in the digital servo.

#5 (MCC) : A magnetic contactor contact in the servo amplifier has welded.

#4 (LDA) : The LED indicates that serial pulse coder C is defective

#3 (PMS) : A feedback pulse error has occured because the feedback cable is

defective.

D Details of servo alarm
