Series 16i/18i/160i/180i/160is/180is - MA Operators manual Page 749

Operators manual
OPERATIONB–63014EN/02 8. DATA INPUT/OUTPUT
729
Outputting offset data
1 Press soft key [OFFSET] on the ALL IO screen, described in Section
8.10.1.
2 Select EDIT mode.
3 Press soft key
[(OPRT)]. The screen and soft keys change as shown
below.
READ/PUNCH (OFFSET) O1234 N12345
MDI
**** *** *** ***
12:34:56
READ PUNCH
I/O CHANNEL 3 TV CHECK OFF
DEVICE NUM. 0 PUNCH CODE ISO
BAUDRATE 4800 INPUT CODE ASCII
STOP BIT 2 FEED OUTPUT FEED
NULL INPUT (EIA) NO EOB OUTPUT (ISO) CR
TV CHECK (NOTES) ON BAUDRATE CLK. INNER
CD CHECK (232C) OFF RESET/ALARM ON
PARITY BIT OFF COM CODE ASCII
END CODE EXT COM PROTCOL A
INTERFACE RS422 SAT COMMAND HOST
(0:EIA 1:ISO)>1_
4 Press soft key [PUNCH], then [EXEC].
The offset data is output, and the ”OUTPUT” indicator blinks at the
lower–right corner of the screen. Upon the completion of output, the
”OUTPUT” indicator is cleared from the screen.
To cancel output, press soft key
[CAN].
Procedure
EXECCAN
