PROGRAMMING 2. CONTROLLED AXES
B–63014EN/02
31
Item
16i–MA
160i–MA
16i–MA, 160i–MA
(two–path control)
No. of basic controlled
axes
3 axes
3 axes for each path
(6 axes in total)
Controlled axes
expansion (total)
Max. 8 axes
(included in Cs axis)
Max. 7 axes for each path
(Feed 6 axes + Cs axis)
Basic simultaneously
controlled axes
2 axes
2 axes for each path
(4 axes in total)
Simultaneously controlled
axes expansion (total)
Max. 6 axes Max. 6 axes for each path
NOTE
The number of simultaneously controllable axes for manual
operation jog feed, manual reference position return, or
manual rapid traverse) is 1 or 3 (1 when bit 0 (JAX) of
parameter 1002 is set to 0 and 3 when it is set to 1).
Item
18i–MA, 180i–MA
No. of basic controlled axes 3 axes
Controlled axes expansion (total)
Max. 6 axes
(included in Cs axis)
Basic simultaneously controlled axes 2 axes
Simultaneously controlled axes expansion (total) Max. 4 axes
NOTE
The number of simultaneously controllable axes for manual
operation jog feed, manual reference position return, or
manual rapid traverse) is 1 or 3 (1 when bit 0 (JAX) of
parameter 1002 is set to 0 and 3 when it is set to 1).
2.1
CONTROLLED AXES
Series 16, Series 160
Series 18, Series 180
