PROGRAMMING

B–63014EN/02

4. INTERPOLATION FUNCTIONS

Spiral interpolation in the XY plane is defined as follows:

(X – X

)

+ (Y – Y

)

= (R + Q’)

: X coordinate of the center

: Y coordinate of the center

R : Radius at the beginning of spiral interpolation

Q’ : Variation in radius

When the programmed command is assigned to this function, the

following expression is obtained:

(X – X

– I)

+ (Y – Y

– J)

(R+ĂĂL'Ă+ąąăQ

360

where

: X coordinate of the start point

: Y coordinate of the start point

I : X coordinate of the vector from the start point to the center

J : Y coordinate of the vector from the start point to the center

R : Radius at the beginning of spiral interpolation

Q : Radius increment or decrement per spiral revolution

L’ : (Current number of revolutions) – 1

θ : Angle between the start point and the current position

(degrees)

Block overlap between a spiral/conical interpolation block and other

blocks is performed only in simple high–precision contour control mode

(see II–19.6). In other modes, the movement is decelerated and stopped

in the block before the spiral/conical interpolation block, after which

interpolation starts. After completion of the spiral/conical interpolation

block, the movement is decelerated and stopped, then the next block is

executed.

For conical interpolation, two axes of a plane and two additional axes, that

is, four axes in total, can be specified. A rotation axis can be specified as

the additional axis.

The spiral or conical interpolation command can be programmed in cutter

compensation C mode. At the start and end points of the block, a virtual

circle around the center of the spiral interpolation is drawn. Cutter

compensation is performed along the virtual circle, then spiral

interpolation is performed about the result of the cutter compensation.

When both the start point and end point are at the center, no virtual circle

can be drawn. If drawing is attempted, P/S alarm No. 5124 is issued.

During spiral interpolation, the function for clamping the feedrate by arc

radius (parameters 1730 to 1732) is enabled. The feedrate may decrease

as the tool approaches the center of the spiral.

When the dry run signal is inverted from 0 to 1 or from 1 to 0 during

movement along an axis, the movement is accelerated or decelerated to

the desired speed without first reducing the speed to zero.

Explanations

D Function of spiral

interpolation

D Movement between

blocks

D Controlled axes

D Cutter compensation C

D Feedrate clamping by

arc radius

D Dry run
