TITLE: PROFIBUS-DP Board OPERATOR’S MANUAL
Status Address Setting for Slave function
B-63994EN/02-2
FANUC LTD.
05.08.09
DRAW.NO.
Setting item
Item Description
Station number of this slave device STATION NO.
Setting range : 0 to 125
Set the start addresses of DI data and DO data.
Input a blank (SP) when you do not want to set this
address. (The indication of non-effective is "- - - - -".)
"DI" and "DO" represent input and output, respectively, as
viewed from the slave station.
DI / DO DATA
ADDRESS
Setting range : See CAUTION below.
Set the sizes of DI data and DO data.
"DI" and "DO" represent input and output, respectively, as
viewed from the slave station.
DI / DO DATA
SIZE
Setting range : 0 to 244 (bytes)
(The total of DI/DO sizes must not exceed
244 bytes.)
Set the address which Status is copied to.
The details of the status are explained in "STATUS"
below.
The following PMC address is set as the initial value
according to the effective PMC Memory Type.
- If PMC Memory-C is not effective :R9094
- If PMC Memory-C is effective : Z0094
If you input a blank (SP), the above initial value is set,
too.
STATUS
ADDRESS
Setting range : See CAUTION below.
