2.PROFIBUS-DP SLAVE FUNCTIONS SETTING B-63994EN/02
- 54 -
2.5 SETTING SLAVE PARAMETERS TO USE A SLAVE
STATION MANUFACTURED BY FANUC
The slave parameters to be set by the master station when a slave
station manufactured by FANUC is used are described below. For
the meanings of the parameters, refer to the manual for the master
station or see "SLAVE PARAMETER screen" in Section 1.1,
"MASTER FUNCTION SETTING".
Display item
Item Setting
IDENT NO. 0805 (Hex)
SLAVE FLAG C0 (Hex)
SLAVE TYPE
０ (Hex)
88 (Hex)
STATION STATUS
(Note) The SYNC function and FREEZE function
are not supported by a slave station
manufactured by FANUC.
Arbitrary
WD FACT1, 2
Set an appropriate value that matches the desired
time for disconnection detection.
Arbitrary
MIN TSDR
Set "0B" (Hex) usually.
０ (Hex)
GROUP IDENT
(Note) GROUP IDENT is valid with a slave station
that supports the SYNC function and the
FREEZE function.
USER PRM DATA Not used (Data length: 0)
Data length : Depends on the input/output size.
Data : Depends on the input/output size.
CONFIG DATA
(Note) See "Explanation of configuration data".
SLAVE USER DATA Not used (Data length: 0)
