B-63994EN/02 SETTING 1.PROFIBUS-DP MASTER FUNCTIONS
- 31 -
The following describes each mode and the identification values
used when giving notification to a PMC address.
Description of each mode and identification values
Item Description
In this mode, communication with all nodes is
disabled.
OFFLINE
Identification value : 0x00
In this mode, communication with another
master station (such as class 2 station) is
enabled.
Communication with a slave station is disabled.
STOP
Identification value : 0x40
In this mode, output (DO) is cleared for all
slave stations for which communication is
enabled.
CLEAR
Identification value : 0x80
In this mode, DI/DO communication is being
performed for all slave stations for which
communication is enabled.
OPEARTE
Identification value : 0xC0
CAUTION
When assigning addresses, keep the following in
mind.
(1) When setting the PMC area, note the following:
The R address or E address can be set.
For a multi-path PMC, enter an PMC address
as follows:
<Path number>:<PMC address>
For R0500 for the second PMC path, for
example, enter "2:R500". When only a PMC
address (R500) is entered, it is assumed to be
the PMC address for the first path (1:R0500).
If the ":" key is not provided, the "/" or "EOB"
key can be used instead.
(2) The DI data area, DO data area, diagnostic
data area, and operation mode display area
cannot overlap each other.
(3) The area assignment area and the area used
by the ladder program cannot overlap each
other.
4 Press soft key [(OPRT)] as needed and then use the following
soft keys.
[INITIALIZE] :
Disables notification to a PMC address.
In this case, "-----" appears in the INDICATION ADDRESS
field.
(The notification is disabled during initial setup.)
