1.PROFIBUS-DP MASTER FUNCTIONS SETTING B-63994EN/02
- 12 -
Setting item
Item Description
STATION NO. Station number of this master device
Fieldbus Data Link Address
BAUDRATE Transfer rate
( 0 : 9.6Kbps, 1 : 19.2Kbps, 2 : 93.75Kbps,
3 : 187.5Kbps, 4 : 500Kbps, 6 : 1.5Mbps,
7 : 3Mbps, 8 : 6Mbps, 9 : 12Mbps )
BP FLAG User Interface Flag
Bit 7 :(EAC)Error Action Flag
0 : Does not change the operation mode if an error
occurs.
1 : Changes the operation mode from Operate
mode to the Clear mode if an error occurs.
Bits 6 to 0 (RSV) are reserved (to be set to 0).
MIN SLAVE
INT
Minimum slave interval for between two slave poll cycles
(Unit: 100 µs)
POLL TIME
OUT
Poll Timeout for the master-master communication
Maximum wait time after the issue of a request for
communication between master stations until a response
is received. (Unit: 1 ms)
DATA
CONTROL
Data Control Time
Time until the data transfer list is updated at least once.
(Unit: 10 ms)
T SL Slot Time
Maximum time from token frame transmission until the
first character of a response frame is read. (Unit: Bit time)
MIN T SDR Minimum Station Delay Time of Responders
Minimum elapsed time from the last bit of send or receive
data to the first bit of the next send or receive data. (Unit:
Bit time)
MAX T SDR Maximum Station Delay Time of Responders
Maximum elapsed time from the last bit of send or receive
data to the first bit of the next send or receive data. (Unit:
Bit time)
T QUI Transmitter fall/Repeater switch Time
Wait time after data transmission until the receiver can be
operated again. (Unit: Bit time)
T SET Setup Time
Time after the occurrence of an event until the execution
of the corresponding action is started. (Unit: Bit time)
T TR Target Rotation Time
Estimated time required for a PROFIBUS token to make
one rotation. (Unit: Bit time)
G Gap Update Factor
Number of tokens that rotate during a gap maintenance
period.
HSA Highest Station Address
Maximum node number that is set for a PROFIBUS
network to be connected to.
MAX RETRY Maximum Number of retries
