2.PROFIBUS-DP SLAVE FUNCTIONS SETTING B-63994EN/02
- 58 -
Examples of setting CONFIG DATA with the master station are
provided below for reference information.
(a) Example of setting CONFIG DATA when both input and output
are used
Input/output sizes of
master station
DI/DO sizes to be set with slave
station manufactured by FANUC
CONFIG DATA to be set with master station
(Equivalent to "Module" of GSD file)
(a)-<1>
Input/output size = 64 / 64
DI/DO SIZE = 64 / 64
Data length: 3
Data: C0 3F 3F
(a)-<2>
Input/output size = 122 / 122
DI/DO SIZE = 122 / 122
Data length: 6
Data: C0 3F 3F C0 39 39
(a)-<3>
Input/output size = 64 / 128
DI/DO SIZE = 128 / 64
Data length: 5
Data: C0 3F 3F 80 3F
(a)-<4>
Input/output size = 1 / 192
DI/DO SIZE = 192 / 1
Data length: 7
Data: C0 3F 00 80 3F 80 3F
(a)-<5>
Input/output size = 1 / 243
DI/DO SIZE = 243 / 1
Data length: 9
Data: C0 3F 00 80 3F 80 3F 80 32
(a)-<6>
Input/output size = 128 / 64
DI/DO SIZE = 64 / 128
Data length: 5
Data: C0 3F 3F 40 3F
(a)-<7>
Input/output size = 192 / 1
DI/DO SIZE = 1 / 192
Data length: 7
Data: C0 00 3F 40 3F 40 3F
(a)-<8>
Input/output size = 243 / 1
DI/DO SIZE = 1 / 243
Data length: 9
Data: C0 00 3F 40 3F 40 3F 40 32
(a)-<9>
Input/output size = 65 / 129
DI/DO SIZE = 129 / 65
Data length: 8
Data: C0 3F 3F C0 3F 00 80 00
(a)-<10>
Input/output size = 129 / 65
DI/DO SIZE = 65 / 129
Data length: 8
Data: C0 3F 3F C0 00 3F 40 00
(b) Example of setting CONFIG DATA when output only is used
Input/output sizes of
master station
DI/DO sizes to be set with slave
station manufactured by FANUC
CONFIG DATA to be set with master station
(Equivalent to "Module" of GSD file)
(b)-<1>
Input/output size = 0 / 64
DI/DO SIZE = 64 / 0
Data length: 2
Data: 80 3F
(b)-<2>
Input/output size = 0 / 128
DI/DO SIZE = 128 / 0
Data length: 4
Data: 80 3F 80 3F
(b)-<3>
Input/output size = 0 / 192
DI/DO SIZE = 192 / 0
Data length: 6
Data: 80 3F 80 3F 80 3F
(b)-<4>
Input/output size = 0 / 244
DI/DO SIZE = 244 / 0
Data length: 8
Data: 80 3F 80 3F 80 3F 80 33
(c) Example of setting CONFIG DATA when input only is used
Input/output sizes of
master station
DI/DO sizes to be set with slave
station manufactured by FANUC
CONFIG DATA to be set with master station
(Equivalent to "Module" of GSD file)
(c)-<1>
Input/output size = 64 / 0
DI/DO SIZE = 0 / 64
Data length: 2
Data: 40 3F
(c)-<2>
Input/output size = 128 / 0
DI/DO SIZE = 0 / 128
Data length: 4
Data: 40 3F 40 3F
(c)-<3>
Input/output size = 192 / 0
DI/DO SIZE = 0 / 192
Data length: 6
Data: 40 3F 40 3F 40 3F
(c)-<4>
Input/output size = 244 / 0
DI/DO SIZE = 0 / 244
Data length: 8
Data: 40 3F 40 3F 40 3F 40 33
