B-63994EN/02 SETTING 2.PROFIBUS-DP SLAVE FUNCTIONS
- 47 -
Display item
Item Description
CONFIG STATUS
The status of configuration data is indicated.
FF : Initial state
00 : Configuration data is valid.
F0 : A slave parameter (parameter data or
configuration data) is invalid.
01 : The length of configuration data is invalid.
02 : Configuration data includes errors.
(Supplement)
If a disconnection is detected, "F0" is initially
set then the status returns to the initial state
"FF" about 20 seconds later.
PARAM STATUS
The status of parameter data is indicated.
FF : Initial state
00 : Parameter data is valid.
F0 : A slave parameter (parameter data or
configuration data) is invalid.
(Supplement)
If a disconnection is detected, "F0" is initially
set then the status returns to the initial state
"FF" about 20 seconds later.
WATCHDOG STATUS
The status of the communication link with the
master station is indicated.
FF : Initial state
00 : Communication being performed normally
01 : Disconnected
(Supplement)
If communication is not established even
once, "FF" (initial state) remains to be set.
When a disconnection is detected after
communication is once established, "01" is
set.
When a disconnection is repaired to return
to normal communication state, "00" is set
again.
IDENT NO.
Identification number of a CNC slave station
manufactured by FANUC
