Profibus DP-Board for Operators manual Page 77

Operators manual
B-63994EN/02 CONNECTION 2.INSTALLATION
- 69 -
2.1 SPECIFICATION
Order specification
Name Specification Remarks
PROFIBUS Master Board A02B-0303-J311 Master function only
PROFIBUS Slave Board A02B-0303-J313 Slave function only
NOTE
When using the board, it is necessary to adhere to
the installation condition (the environmental
condition in the cabinet) of the CNC control unit in
which the board is installed.
The table below indicates the power supply capacities and heating
values of the PROFIBUS boards. For the values of the main CNC unit
and optional units, refer to the connection manual of the CNC.
Name Power supply capacity Heating value
PROFIBUS Master Board 0.2A 5W
PROFIBUS Slave Board 0.1A 2W
