2.6.3. P-Code Variable Screen displayed not displayed 2.6.3. P-Code Variable Screen displayed not displayed
The PMC control of the application to open the P-CODE VARABLE SCREEN or not. The PMC control of the application to open the P-CODE VARABLE SCREEN or not.
#7 #7 #6 #6 #5 #5 #4 #4 #3 #3 #2 #2 #1 #1 #0 #0
D-Base
Addr + 3
PCDS
[Direction] from PMC to Macro Executor Application Program
[Data Type] Bit [PCDS] Status: P-Code Variable Display Status
0: The P-Code Variable Screen can be not displayed.
1: The P-Code Variable Screen can be displayed.
Note: This function is always active and independently of the RUN / STOP status.
The MTB has to take care that the end-user isn’t able in any case
to set this bit to one
Attention:
In case of service (program debugging) it must be somehow possible with secret information to set this
bit to one.
2.6.4. Supported Axis Tool-Post Measurement Process enable/disable
The PMC control of the application ot the type of measurement TOOL or TOOL Post.
#7 #6 #5 #4 #3 #2 #1 #0
D-Base
Addr + 2
TPMP
[Direction] from PMC to Macro Executor Application Program
[Data Type] Bit [TPMP] Mode: Tool Post Measurement Process
0: The Turret Tool-Post Measurement Process is inactive.
1: The Turret Tool-Post Measurement Process is active.
The default mode is Tool Post measurement disabled (TPMP=0)
Note: The Tool Post measurement function is only for machine set-up or maintenance and not for the
end-user.
Attention:
The MTB has to take care that the end-user isn’t able in any case
to set this bit to one.
In case of service (program debugging) it must be somehow possible with secret information to set this
bit to one.
——————————————————————————————————————
Sauter-Turret and
2
nd
Geometry Tool Data
and
2
nd
Geometry Tool Data
6.0 6.0
28
th
January 2003 28
th
January 2003
