  2. Sauter-Turret with 2nd Geometry Tool Offset Data Function for 16i-TB, 18i-TB, 21i-TB

Sauter-Turret with 2nd Geometry Tool Offset Data Function for 16i-TB, 18i-TB, 21i-TB Additional Manual Page 61

Additional Manual
B–63523EN–1/02
14. MEASUREMENT
1685
[Classification] Output signal
[Function] For the tool setter function of the one–turret/two–spindle lathe, it is
indicated which spindle, 1 or 2, is under measurement.
[Output condition] These signals check which head is being measured in the tool
compensation amount write mode or workpiece coordinate system shift
amount write mode according to the S2TLS (spindle measurement select)
signal.
If spindle 1 is selected, S1MES = 1 and S2MES = 0. If spindle 2 is
selected, S1MES = 0 and S2MES = 1.
#7
X004
#6 #5
–MIT2
SKIP5
#4
+MIT2
SKIP4
#3
–MIT1
SKIP3
#2
+MIT1
SKIP2
#1 #0
#7
X004
#6 #5
–MIT2
#1
SKIP5
#1
#4
+MIT2
#1
SKIP4
#1
#3
–MIT1
#1
SKIP3
#1
#2
+MIT1
#1
SKIP2
#1
#1 #0
X013 –MIT2
#2
SKIP5
#2
+MIT2
#2
SKIP4
#2
–MIT1
#2
SKIP3
#2
+MIT1
#2
SKIP2
#2
WARNING
Since the same addresses are used for both +MIT1, –MIT1,
+MIT2, –MIT2 and skip signals SKIP2 to SKIP5 (multi–step
skip), be careful when using these two signal types.
#7
GOQSMG039
#6
WOQSM
#5
OFN5
#4
OFN4
#3
OFN3
#2
OFN2
#1
OFN1
#0
OFN0
WOSETG040 S2TLS OFN6
F062 S2MES S1MES
Spindle 1 under
measurement signal
S1MES <F062#3>
Spindle 2 under
measurement signal
S2MES <F062#4>
Signal address
(1–path control)
(2–path control)
Previous page
Next page
