  2. Sauter-Turret with 2nd Geometry Tool Offset Data Function for 16i-TB, 18i-TB, 21i-TB

Sauter-Turret with 2nd Geometry Tool Offset Data Function for 16i-TB, 18i-TB, 21i-TB Additional Manual Page 28

Additional Manual
GE Fanuc Automation
Version: 23
GFTE-557E-EN
5.2. Sauter Application as stand alone Application
The MTB has to set the Macro Executer related options and to load the MEM-File, which is already
prepared by GE Fanuc Europe. In this case the preparation doesn’t need any customer related information
needed for this application type.
5.3. Sauter Application with Customer Macro Executer Application
5.3.1. Requested Information
GE Fanuc needs to prepare the correct REL-Files the following information:
1. The PMC-Base D- or R-Address with 10 free bytes afterwards.
2. The Base P-Code Variable Address with 20 free P-Code variables afterwards.
3. The Base program number with 10 free numbers afterwards.
4. Selection of D- or R-Address area
Attention:
The given resources (except point 4) can’t be used by customer’s
application any more.
With this information the MTB will received the following prepared REL-Files:
1. MESSAGES.REL
2. PCM_IO.REL
3. SAUTER.REL
and the necessary Macro Executor Executor-File (finame_name.MEX) for the related control.
——————————————————————————————————————
Sauter-Turret and
2
nd
Geometry Tool Data
6.0
28
th
January 2003
