Sauter-Turret with 2nd Geometry Tool Offset Data Function for 16i-TB, 18i-TB, 21i-TB Additional Manual Page 35

Additional Manual
2/6
TITLE
NO.
FANUC Series 16i/18 i/21i/-TA
2nd Geometry Tool offset (32)
Specifications
A76410E
PAGE
DS0100-04
01 15.Feb.01 Newly registered
EDT DATE. DESIG. DESCRIPTION
1. General
In the current 2nd Geometry tool offset function, 16 groups of 2nd Geometry tool offsets can be used now.
By using this function, 32 groups of 2nd Geometry tool offsets can be used.
2. Specifications
By using this function, the number of 2nd Geometry tool offset groups in becomes 32. The specification
such as the command format, display, the setting of data, signals, and parameters follows ones of the
current 2nd Geometry tool offset function.
(In this document, a current geometry offset is called 1
st
geometry tool offset.)
2.1 Command Format
The 2
nd
geometry tool offset is commanded by T code with four digits. According to the status of the signal
G2SLC, the geometry offset becomes only 1
st
geometry tool offset or the amount of 1
st
and 2
nd
geometry tool
offset.
When the 2nd geometry tool offset is added to the 1st geometry tool offset, the axis using the 2nd geometry
tool offset is selected by the 2nd tool offset axis selecting signals G2X, G2Z, G2Y.
T gg ww
Wear tool offset number
1st geometry tool offset number
or
1st + 2nd geometry tool offset number
(NOTE1) Set these parameters as follows in case of using this function.
• LD1(No.5002#0)=0: Offset number of tool offset (Wear offset number when option of tool
geometry/wear compensation is selected) is specified by the lower two digits
of a T code.
• LDN(No.5002#1)=1: Geometry offset number of tool offset (When the option of tool geometry/wear
compensation is selected, it is effective.) is specified by the tool selection
number.
