Sauter-Turret with 2nd Geometry Tool Offset Data Function for 16i-TB, 18i-TB, 21i-TB Additional Manual Page 87

Additional Manual
B–63523EN–1/02
1. AXIS CONTROL
123
1220 External workpiece zero point offset value
[Data type] Two–word axis
Input increment IS–A IS–B IS–C Unit
Linear axis (input in mm) 0.01 0.001 0.0001 mm
Linear axis (input in inches) 0.001 0.0001 0.00001 inch
Rotation axis 0.01 0.001 0.0001 deg
[Valid data range] –99999999 to 99999999
This is one of the parameters that give the position of workpiece
coordinate system (G54 to G59). It gives an offset of the workpiece zero
point common to all workpiece coordinate systems. In general, the offset
varies depending on the workpiece coordinate systems. The parameter
value can also be set from the PMC by using the external data input
function.
1221 Workpiece zero point offset value in workpiece coordinate system1 (G54)
1222 Workpiece zero point offset value in workpiece coordinate system2 (G55)
1223 Workpiece zero point offset value in workpiece coordinate system3 (G56)
1224 Workpiece zero point offset value in workpiece coordinate system4 (G57)
1225 Workpiece zero point offset value in workpiece coordinate system5 (G58)
1226 Workpiece zero point offset value in workpiece coordinate system6 (G59)
[Data type] Two–word axis
Input increment IS–A IS–B IS–C Unit
Linear axis (input in mm) 0.01 0.001 0.0001 mm
Linear axis (input in inches) 0.001 0.0001 0.00001 inch
Rotation axis 0.01 0.001 0.0001 deg
[Valid data range] –99999999 to 99999999
The workpiece zero point offset values in workpiece coordinate systems 1
to 6 (G54 to G59) are set.
[Unit of data]
[Unit of data]
