Series 20i-MODEL A Parameter manual Page 110

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63380EN/02
106
3421 Minimum value 1 of M code preventing buffering
3422 Maximum value 1 of M code preventing buffering
3423 Minimum value 2 of M code preventing buffering
3424 Maximum value 2 of M code preventing buffering
3425 Minimum value 3 of M code preventing buffering
3426 Maximum value 3 of M code preventing buffering
3427 Minimum value 4 of M code preventing buffering
3428 Maximum value 4 of M code preventing buffering
3429 Minimum value 5 of M code preventing buffering
3430 Maximum value 5 of M code preventing buffering
3431 Minimum value 6 of M code preventing buffering
3432 Maximum value 6 of M code preventing buffering
[Data type] Word
[Valid data range] 0 to 65535
When a specified M code is within the range specified with parameter
Nos. 3421 and 3422, 3423 and 3424, 3425 and 3426, 3427 and 3428, 3429
and 3430, or 3431 and 3432, buffering for the next block is not performed
until the execution of the block is completed.
NOTE
1 The specification of a minimum value that exceeds the
specified maximum value is invalid.
2 When there is only one data item, set the following:
minimum value = maximum value.
#7
3450
#6 #5 #4
NPS
#3
CQD
CQD
#2 #1 #0
[Data type] Bit
CQD The method used for determining the amount of travel in circular
interpolation is:
0 : FS16 type.
1 : FS15 type.
NPS A block that contains M98 Pxxx or M99, and which contains no addresses
other than O and N functions:
0 : As a one–block NC statement involving no movement.
(A single–block stop is caused.)
1 : As a macro statement.
(A single–block stop is not caused. Moreover, the block is not
regarded as a block involving no movement in tool–tip radius
compensation mode.)
