Series 20i-MODEL A Parameter manual Page 174

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63380EN/02
170
6581 Standard color data for character color number 1
6582 Standard color data for character color number 2
6583 Standard color data for character color number 3
6584 Standard color data for character color number 4
6585 Standard color data for character color number 5
6586 Standard color data for character color number 6
6587 Standard color data for character color number 7
6588 Standard color data for character color number 8
6589 Standard color data for character color number 9
6590 Standard color data for character color number 10
6591 Standard color data for character color number 11
6592 Standard color data for character color number 12
6593 Standard color data for character color number 13
6594 Standard color data for character color number 14
6595 Standard color data for character color number 15
[Data type] 2–word
[Unit of data] rr gg bb: 6–digit number (rr: Red gg: Green bb: Blue)
When a number of less than six digits is set, the system assumes that 0 has
been specified for the unspecified higher digit(s).
[Valid data range] Data of each color: 00 to 15 (same value as the tone level data on the color
setting screen)
When a value of more than 15 is set, the system assumes that 15 has been
specified.
Example: Set 10203 in this parameter when the color tone levels are as
follows:
Red: 1 Green: 2 Blue: 3
NOTE
To set the color of the VGA display, use the color setting
screen. Note that the color changes when the settings of
parameters No.6561 through No.6595 are modified.
