Series 20i-MODEL A Parameter manual Page 206

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63380EN/02
202
#7
9343
#6 #5 #4 #3 #2 #1
C99
#0
CST
CST 0 : Contour programming cannot be called from machining guidance
1 : Contour programming can be called from machining guidance
C99 0 : When contour programming is called from machining guidance, M99
is not outputted at the end of converted NC program.
1 : When contour programming is called from machining guidance, M99
is outputted at the end of converted NC program.
9344 Color number of guidance drawing (Contour)
9345 Color number of guidance drawing (End point)
9346 Color number of guidance drawing (Center point)
9347 Color number of guidance drawing (Result figure)
9348 Color number of guidance drawing (Pass point)
9349 Color number of guidance drawing (Base point / line)
9350 Color number of guidance drawing (Measure line)
9351 Color number of guidance drawing (Auxiliary line)
9352 Color number of guidance drawing (Shift line)
9353 Color number of guidance drawing (Another point in selection)
Enter color number (1 to 15) according to the CNC screen COLORING.
Correspondence between color number and actual color can be verified on
this COLORING screen. When 0 is entered, corresponding drawing is
displayed in black.
When you use these parameters, set parameter No.9442#0(COL) to 1.
9360 Macro program number executed at the end of contour programming
When contour programming that was called from machining guidance is
finished and returns to the previous screen, machining guidance, the
custom macro program with this program number is called and executed.
If certain custom macro program should be executed after this program,
call it at the end of this macro program.
When 0 is set in this parameter, the custom macro program that was
executed when contour programming was called will be executed again.
9361 Program number in which converted NC program will be made
When NC program conversion is done in a contour programming which
was called from machining guidance, the NC program will be made as a
program with this program number.
If 0 is set in this parameter, a warning message will be displayed and NC
program conversion cannot be started.
This program will be deleted once when NC program conversion begins.
