Series 20i-MODEL A Parameter manual Page 171

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
167
#7
6500
#6
NZM
#5
DPO
#4 #3
DPA
#2 #1 #0
[Data type] Bit
DPA Current position display on the graphic display screen
0 : Displays the actual position to ensure tool nose radius compensation
1 : Displays the programmed position
DPO Current position on the solid drawing (machining profile drawing) or tool
path drawing screen
0 : Not appear
1 : Appears
NZM 0 : The screen image is not enlarged by specifying the center of the screen
and magnification. (Screen image enlargement by a conventional
method is enabled.)
1 : The screen image is enlarged by specifying the center of the screen
and magnification. (Screen image enlargement by the conventional
method is disabled.)
#7
6501
#6 #5
CSR
CSR
#4
FIM
#3
RID
#2
3PL
#1
TLC
#0
ORG
[Data type] Bit
ORG Movement when coordinate system is altered during drawing
0 : Draws in the same coordinate system
1 : Draws in the new coordinate system (only for the path drawing)
TLC In solid drawing
0 : Not compensate the tool length
1 : Compensates the tool length
3PL Tri–plane drawing in solid drawing
0 : Drawn by the first angle projection
1 : Drawn by the third angle projection
RID In solid drawing
0 : Draws a plane without edges.
1 : Draws a plane with edges.
FIM Machining profile drawing in solid drawing
0 : Displayed in the coarse mode
1 : Displayed in the fine mode
CSR While the screen image is enlarged, the shape of the graphic cursor is:
0 : A square. (J)
1 : An X. (X)
4.23
PARAMETERS OF
GRAPHIC DISPLAY
4.23.1
Parameters of Graphic
Display/Dynamic
Graphic Display
