Series 20i-MODEL A Parameter manual Page 165

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
161
SBM Custom macro statement
0: Not stop the single block
1: Stops the single block
NOTE
When parameter No.3404 #0 NOP = 1, it becomes invalid.
#7
CLV6001
#6
CCV
#5
TCS
#4
CRO
#3
PV5
#2 #1
PRT
#0
[Data type] Bit
PRT Reading zero when data is output using a DPRINT command
0 : Outputs a space
1 : Outputs no data
PV5 Custom macro common variables:
0 : Nos. 500 to 599 are output.
1 : Nos. 100 to 199 and Nos. 500 to 599 are output.
CRO ISO code in BPRWT or DPRNT commond
0 : Outputs only LF after data is output
1 : Outputs LF and CR after data is output
TCS Subprogram
0 : Not called using a T code
1 : Called using a T code
CCV Custom macro’s common variables Nos. 100 through 149 (to 199)
0: Cleared to “vacant” by reset
1: Not cleared by reset
CLV Custom macro’s local variables Nos. 1 through 33
0: Cleared to “vacant” by reset
1: Not cleared by reset
#7
6004
#6 #5 #4 #3 #2
VHD
#1 #0
NAT
NAT
[Data type] Bit
NAT Specification of the results of custom macro functions ATAN and ASIN
0 : The result of ATAN is 0 to 360.0.
The result of ASIN is 270.0 to 0 to 90.0.
1 : The result of ATAN is –180 to 0 to 180.0.
The result of ASIN is –90.0 to 0 to 90.0.
VHD With system variables #5121 through #5122
0 : Tool position offset values (geometry offset values) are read.
1 : The amount of interrupt shift caused by a manual handle interrupt is
read.
