4. DESCRIPTION OF PARAMETERS
117
3732
The spindle speed during spindle orientation or the spindle motor speed
during spindle gear shift
[Data type] Word
[Valid data range] 0 to 20000
Set the spindle speed during spindle orientation or the spindle motor
speed during gear shift.
When GST, #1 of parameter 3705, is set to 0, set the spindle speed during
spindle orientation in min
–1
.
When GST, #1 of parameter 3705, is set to 1, set the spindle motor speed
during spindle gear shift calculated from the following formula.
Set value =
× 16383
Spindle motor speed during spindle gear shift
Maximum spindle motor speed
For a serial spindle
Set value =
× 4095
Spindle motor speed during spindle gear shift
Maximum spindle motor speed
For an analog spindle
3735
Minimum clamp speed of the spindle motor
[Data type] Word
[Valid data range] 0 to 4095
Set the minimum clamp speed of the spindle motor.
Minimum clamp speed of the spindle motor
Set value =
× 4095
Maximum spindle motor speed
