FANUC LASER-MODEL C1000iA Operators manual Page 62

Operators manual
B-70254EN/01 C.PARAMTER LIST
- 59 -
LHC
0: Does not control the oscillator with external signals (standard).
1: Controls the oscillator with external signals.
In the automatic operation mode, external signals are used to
turn on and off the shutter and beam output.
#7 #6 #5 #4 #3 #2 #1 #0
15002 PSH ADC BMA
Data type: Bit
BMA
0: Disables beam output with the shutter closed in the automatic
operation mode (standard).
1: Enables beam output with the shutter closed in the automatic
operation mode (for maintenance).
ADC
0: Uses the select signal to determine AD converter 2 data.
1: the DI signal to determine AD converter 2 data. (standard)
PSH
0: Uses all discharge tubes.
1: Uses half of the discharge tubes.
#7 #6 #5 #4 #3 #2 #1 #0
15003 GVW HPT TIV
Data type: Bit
TIV
0: Inverts the sign (+/-) of the amount of tracing displacement.
1: Does not invert the sign (+/-) of the amount of tracing
displacement.
HPT
0: Rewrites parameter settings for extending or shortening piercing.
1: Does not rewrite parameter settings for extending or shortening
piercing.
GVW
0: Disables evacuation when RUN is turned off.
1: Enables evacuation when RUN is turned off.
#7 #6 #5 #4 #3 #2 #1 #0
15004 CWY ECH EDG SPB STC AGC
Data type: Bit
AGC
0: Uses the "G32 P_;" command (when Q, T, and R are not
specified) as the flow pattern command.
1: Uses the "G32 P_;" command (when Q, T, and R are not
specified) as the gas pressure control direct command.
STC
0: Controls the shutter with a G code.
1: Controls the shutter with an external signal.
