2.OPERATING THE MACHINE REMOTE DIAGNOSIS FUNCTIONS OPERATION B-64014EN/03
- 114 -
2.1.1 Selecting an Inquiry Destination
Select an inquiry destination among inquiry destinations 1 to 3.
1 Press soft key [(OPRT)].
2 Press soft key [INQUIRY1] to select inquiry destination 1.
3 Similarly, press soft key [INQUIRY2] to select inquiry
destination 2 and soft key [INQUIRY3] to select inquiry
destination 3.
2.1.2 Starting Diagnosis
Start diagnosis.
1 Press soft key [(OPRT)].
2 Press soft key [DIAG OPEN] to start diagnosis.
2.1.2.1 Diagnosis status
Status Description
--- No operation
OPEN [DIAG OPEN] was pressed.
OPENING
An attempt is being made to connect the machine
remote diagnosis accepting server.
ACCEPTED
The machine remote diagnosis accepting server
accepted diagnosis.
REFUSED
The machine remote diagnosis accepting server
rejected diagnosis.
DIAGNOSING
This message flashes in synchronization with data
flowing on the communication line.
CLOSE
The machine remote diagnosis accepting server
terminated diagnosis.
FORCE CLOSING
[DIAG CLOSE] was pressed. After the completion of
forced termination processing, "---" is indicated in the
RMT DIAG STATUS field.
ERROR An error occurred on the communication line.
Previous page
Next page
