2.SETTING THE DATA SERVER FUNCTIONS SETTING B-64014EN/03
- 44 -
0923 Selects the host computer 3 OS.
[Data type] Byte
[Valid data range] 0 to 2
0: Windows 95/98/Me/2000/XP.
1: UNIX/VMS.
2: Linux.
0930
Maximum number of files that can be registered to the memory card of the
Data Server and maximum size per file that can be registered
[Data type] Byte
[Valid data range] 0, 10 to 15
No.930 Maximum number of files Maximum size per file
0 2047 512MB
10 511 2048MB
11 1023 1024MB
12 2047 512MB
13 4095 256MB
14 8191 128MB
15 16383 64MB
NOTE
1 When the memory card is formatted after this
parameter is set, the maximum number of files and
maximum size per file are changed.
2 Each folder is counted as one file.
3 This parameter is valid when the series and edition
of the Data Server function software are edition 11
or later of series 6569.
#7 #6 #5 #4 #3 #2 #1 #0
3107 SOR
[Data type] Bit
SOR In the Data Server FILE LIST screen, files are displayed:
0: In the order of zero-suppressed program number.
1: In the order of program name.
#7 #6 #5 #4 #3 #2 #1 #0
3193 ODR
[Data type] Bit
ODR In the file list display of the Data Server, the program size is indicated in:
0: KB
1: Pages
#7 #6 #5 #4 #3 #2 #1 #0
3233 PDM
[Data type] Bit
PDM When the Data Server FILE LIST screen is displayed:
1: The setting of a foreground/background folder is enabled.
0: The setting of an M198 operation folder/DNC operation file is
enabled.
