30i/300i/300is-Model A Macro Compiler/Macro Executor Programming manual Page 117

Programming manual
B-63943EN-2/01 6.MACRO EXECUTOR FUNCTION
- 107 -
List of macro executor functions, related G codes, and related control variables
Section Function Outline of function Related G code
Related control
variable
Conversational
Auxiliary
Execution
6.1 Screen display functions
Controls conversational macro
screen display.
(Control on character display,
graphic display, cursor display,
and so forth)
G202, G240, G242,
G243, G244, G250,
G01, G02, G03,
G230, G249, G280,
G390, G391, G392,
G311, G300, G206,
G204, G317
#8509, #8510,
#8571
6.2
Key input and data
input/output
Reads MDI key input states,
input data values, and so forth.
____
#8501, #8502,
#8503, #8504,
#8508, #8552,
#8549, #8533
6.3 Address functions
Reads the data of PMC
addresses or CNC parameter
values.
____ ____
6.4 PMC address reading/writing
Reads and writes the data of
PMC addresses D, R, C, K, and
T.
G310 ____
6.5
6.6
Reader/punch interface /
Memory card control
Exercises RS232C and memory
card control.
G330 to G339 #8537 to #8539
6.7
CNC program referencing and
writing, and program
information reading
Registers, deletes, and modifies
CNC part programs, and reads
program information and
background state.
G320 to G322
G325 to G329
#8520 to #8523
#8525 to #8529
6.8
Cutting Time and Distance
Read and Preset Functions
Reads and presets cutting time
and cutting distance.
____ #8553, #8554
6.9
Relative Coordinate Read and
Preset Functions
Reads and presets relative
coordinates.
G310 #8996 to #8999
6.10
Array-Type Processing and
Referencing of P-CODE
Variables
Controls processing of array-
type variables or a variable
string in handling of macro
variables.
G315 #8511 to #8519
6.11 Torque Limit Override Control
Enables the torque limit override
value to be changed to a
specified value.
____
#8990 to #8993
#8621 to #8628
6.12 PMC axis control
Enables PMC controlled axes to
be controlled through the PMC
axis control interface.
G340, G341, G344,
G345, G346, G348,
G349, G350, G351
#8602
6.13 File control
Creates and deletes files, and
reads and writes data.
FGEN, FDEL,
FOPEN, FCLOS,
FREAD, FWRIT,
FPSET
____
6.14
Axis-direction-by-axis-
direction interlock function
Enables interlock in each axis
direction, and enables a move
axis and move direction on the
rising edge of the signal to be
known.
____
#8600, #8607,
#8601, #8608
