7.DEBUGGING FUNCTION B-63943EN-2/01

- 276 -

- Temporarily erasing and displaying the debugger screen

The debugger screen can be erased and displayed temporarily.

Press

SHIFT

and

. The debugger screen is erased and re-

displayed alternately.

Setting from the debugger screen

When setting single-block execution and break conditions, switch the

key input mode to key input from the debugger.

Then, use cursor keys

to move the cursor

to an item you want to set.

Key input switching

To perform key input switching, press

SHIFT

and

. When the

key input mode has been changed, INPUT appears on the debugger

screen.

INPUT on the debugger

screen disappears.

Conversational

macro input

enabled

Debugger

input enabled

Press

SHIFT

INPUT appears on the

debugger screen.

NOTE

When a P-CODE macro is stopped by single-block

execution or the break function, the key input mode

switches to the debugger input automatically.

Setting a target

Set a P-CODE macro to be debugged. The P-CODE macro must be in

the stopped state. If the P-CODE macro is not stopped, set single-

block execution to ON to stop the macro.

To set a target, move the cursor to the target, then press

INPUT

Pressing

INPUT

selects the conversational macro and auxiliary macro

alternately.

Immediately after power is turned on, the conversational macro is

initially selected. Later, the target set with the debugger is selected.

NOTE

When switching between targets is performed,

execution of the P-CODE macro that has been set

as the target so far starts. For a new target P-

CODE macro, single-block execution and the break

function are enabled.
