FANUC PMC Simulator, Operator Additional Manual Page 56

Additional Manual
FANUC PMC Simulator
Operator’s Manual
01 05.08.01
T.Maruyama
New registration
A-90139EN/01
EDIT
DATE
DESIG.
DESCRIPTION
56/70
DRAW.NO.
7 COMMUNICATION WITH FANUC
LADDER-III
7.1 OUTLINE
The online connection with FANUC LADDER-III is possible in PMC
simulator by using the network communication function. The following
online functions equal with the case where FANUC LADDER-III is
connected with actual PMC can be used.
• Monitor display of ladder
• Online edit of ladder
• Display and change in PMC parameter
• Monitor display in state of signal
• I/O with PMC(load from PMC and store to PMC)
The PMC simulator and FANUC LADDER-III can be connected either
on the same PC or on different PCs.
About the setting content
The list of a necessary setting for the online connection of the PMC
simulator and FANUC LADDER-III is as follows.
Table 7.1 setting content
Operation
mode
Connection
PMC simulator
Coordinated CNC/PMC simulator
mode
Same PC Port number (Simulator)
Host setting(FANUC LADDER-III)
Hyper Threading(PC)
Port number (Simulator)
Host setting(FANUC LADDER-III)
Ethernet function(Simulator)
Hyper Threading(PC)
Different PC Port number (Simulator)
Host setting(FANUC LADDER-III)
Port number (Simulator)
Host setting(FANUC LADDER-III)
Ethernet function(Simulator)
