FANUC PMC Simulator, Operator Additional Manual Page 7

Additional Manual
FANUC PMC Simulator
Operator’s Manual
01 05.08.01
T.Maruyama
New registration
A-90139EN/01
EDIT
DATE
DESIG.
DESCRIPTION
7/70
DRAW.NO.
• The following function codes of the window functions are not
supported. When the window function is executed, the completion
code and the data area after executing the window instruction reaches
the following values.
Table 1.1.2 (b) Unsupported window function list
Group
Function
Code
Description Completion
Code
Data area
CNC
information
59 Reading the P-code macro variable
3 Undefined
60 Writing the P-code macro variable
3 Undefined
395 Reading the pitch error compensation data
1 Undefined
396 Writing the pitch error compensation data
3 Undefined
Axis
information
30 Reading the servo delay for controlled axes
0 0
31 Reading the acceleration/deceleration delay on controlled axes
0 0
34 Reading the feed motor load current value (A/D conversion data)
0 0
50 Reading the actual spindle speed
4 Undefined
138 Reading actual spindle speeds
0 0
152 Entering torque limit data for the digital servo motor
0 Undefined
153 Reading load information of the spindle motor (serial interface)
0 0
207
Reading the actual speed of servo motor 0 0
211 Reading the estimate disturbance torque data
1 Undefined
413 Reading the three-dimensional error compensation data
6 Undefined
414 Writing the three-dimensional error compensation data
6 Undefined
Tool life
management
functions
- Whole
Undefined Undefined
* Meaning of the table value
Completion code Meaning
0 Normal termination
1 Error (invalid function code)
3 Error (invalid data number)
4 Error (invalid data attribute)
6 Error (necessary option missing)
Data area Meaning
0 The result of executing reading the window becomes 0
• In addition, the simulator might not correspond to the functions
added and changed with recent CNC and PMC because the timing of
creating the software version of CNC and PMC differs from the
CNC and PMC simulator.
