DeviceNet Board Operators manual Page 148

Operators manual
A.DEVICE PROFILES AND OBJECT LIBRARIES APPENDIX B-63404EN/03
- 136 -
Section Information Maximum number of instances
Instance type Bit Strobed I/O 1
Production trigger Cyclic
Transport type Server
Transport class 2
ID Description
GET SET Value
1 State O X
2 Instance type O X 01H
3 Transport class trigger O X 82H
4 Produced connection ID O X
5 Consumed connection ID O X
6 Initial comm. Characteristics O X 02H
7 Produced connection size O X (*)
8 Consumed connection size O X 0800H
9 Expected packed rate O O
12 Watchdog time-out action O O 00
13 Produced
connection path length
O X 0600
14 Produced connection path O X 20_04_24_01_30_03
15 Consumed
connection path length
O X 0000
16 Consumed connection path O X No data
Attribute
17 Production inhibit time O X 00
DeviceNet service Parameter option
05H Reset No
0EH Get_attribute_Signle No
Object
instance 3
Service
10H Set_attribute_Signle No
* Number of IN bytes used, in which the upper byte has been
replaced with the lower byte (example: 0800H when 8 bytes
are used)
For the bit strobe, up to 8 bytes are usable.
