DeviceNet Board Operators manual Page 77

Operators manual
B-63404EN/03 OPERATION 1.DeviceNet FUNCTIONS
- 65 -
28016 Status information data buffer area
[Data type] Byte
[Data range] 0
Sets the area to be used as the status information data buffer. Use the
R area as the address to be set.
This parameter is equivalent to the buffer area setting in "8 STATUS
ADDRESS" in screen 1.3(a) or 1.3(c).
Setting Value Buffer Area
0 R area
28017 Status information data buffer address
[Data type] Word
[Data range] 0 to (value obtained by subtracting the setting value of No.28108 from
the maximum value of the R area)
Sets the leading address of the status information data buffer. Set the
leading address of the buffer.
This parameter is equivalent to the buffer address setting in "8
STATUS ADDRESS" in screen 1.3(a) or 1.3(c).
28018 Status information data buffer size
[Data type] Byte
[Data range] 0 to 4
Sets the size of the status information data buffer. Set the size of the
buffer within the range 0 to 64.
This parameter is equivalent to the "9 STATUS SIZE" setting in
screen 1.3(a) or 1.3(c).
28019 Holding/Clearing the DI data
[Data type] Byte
[Data range] 0, 1
Sets the state of the DI data when communication is not normal.
This parameter is equivalent to the "10 HOLD/CLEAR" setting in
screen 1.3(a) or 1.3(c).
Setting Value Meaning
0 Holding the DI data
1 Clearing the DI data
