DeviceNet Board Operators manual Page 34

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 22 -
Table 1.2.1 (c) (continued): Relationship between setting values of
STATUS SIZE and STATUS information
Setting
Value
Item Description
This 1-byte data indicates the
communications status with each node
having slave No. 17 to 24 in each of its
respective eight bits.
Bit #7 #6 #5 #4 #3 #2 #1 #0
Node 24 23 22 21 20 19 18 17
Slave communications
status 3
(slave No. 17 to 24)
4
Slave communications
status 3
(slave No. 17 to 24)
Communications status (common to all
bits)
1: Enables communications. (normal
communications status)
0: Disables communications.
This 1-byte data indicates the
communications status with each node
having slave No. 25 to 32 in each of its
respective eight bits.
Bit #7 #6 #5 #4 #3 #2 #1 #0
Node 32 31 30 29 28 27 26 25
5 Slave communications
status 4
(slave No. 25 to 32)
Communications status (common to all
bits)
1: Enables communications. (normal
communications status)
0: Disables communications.
6 COMMUNICATION
STATUS:
IDLE/ACTIVE
information
This 1-byte data notifies the PMC of the
state of Group 2 Master/Slave
Connection Set of the DeviceNet.
00h: IDLE state
01h: ACTIVE state
This 1-byte data notifies the PMC of
CAN BUS STATUS1 information.
#7 #6 #5 #4 #3 #2 #1 #0
[ML] [RO] [TO] [TA] [ A ] [BO] [BW] [OL]
7 COMMUNICATION
STATUS: CAN BUS
STATUS1 information
For details, refer to the CAN BUS
STATUS1 information described above.
This 1-byte data notifies the PMC of
CAN BUS STATUS2 information.
#7 #6 #5 #4 #3 #2 #1 #0
[SA] [05] [02] [01] [--] [--] [BP] [ER]
8 COMMUNICATION
STATUS: CAN BUS
STATUS2 information
For details, refer to the CAN BUS
STATUS1 information described above.
