DeviceNet Board Operators manual Page 30

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 18 -
Table 1.2.1 (a): Bus parameter setup items
Item Description
1.DIS/ENB
(DISABLE/ENABLE)
Sets whether to disable or enable
communications.
Move the left and right cursor keys to select this
parameter setting. (For the 15i-A, use soft keys.)
Set ENABLE after setting of the master function
parameters is completed.
Communications is started several seconds after
setting ENABLE.
ENABLE : Enables communications.
DISABLE : Disables communications.
2.MAC-ID Sets the number for identifying on the network the
DeviceNet interface board mounted on the control
unit (CNC).
Set a number that does not duplicate the MAC-ID
of other nodes on the network within the range 0 to
63.
(MAC-ID: Media Access Control ID)
3.BAUD-RATE Sets the baud rate.
The setting range is 0 to 2.
The baud rate for each setting is as follows:
0: 125 kbps
1: 250 kbps
2: 500 kbps
The baud rate is limited by the maximum network
length and other factors. For details, refer to
"Connecting DeviceNet Functions" in the
Connections Manual.
4.STATUS ADDRESS
5.STATUS SIZE
Set the areas to be used as the status information
data buffer.
Set the leading buffer address and buffer size.
Use the R area as the address to be set.
Size setting range: 0 to 8
6.DI HOLD/CLEAR
Note) See Chapter 2,
"Configuring a
Safe System."
Specify whether to hold or clear DI data if
communication is abnormal.
0: To hold DI data.
1: To clear DI data.
