DeviceNet Board Operators manual Page 52

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 40 -
28117 Status information data buffer address
[Data type] Word
[Data range] 0 to (value obtained by subtracting the setting value of No.28118 from
the maximum value of the R area)
Sets the leading address of the status information data buffer.
This parameter is equivalent to the buffer address setting in "4
STATUS ADDRESS" in screen 1.2.1(a) or 1.2.1(b).
28118 Status information data buffer size
[Data type] Byte
[Data range] 0 to 4
Sets the size of the status information data buffer.
This parameter is equivalent to the "5 STATUS SIZE" setting in
screen 1.2.1(a) or 1.2.1(b).
28119 Holding/Clearing the DI data
[Data type] Byte
[Data range] 0, 1
Sets the state of the DI data when communication is not normal.
This parameter is equivalent to the "6 HOLD/CLEAR" setting in
screen 1.2.1(a) or 1.2.1(b).
Setting Value Meaning
0 Holding the DI data
1 Clearing the DI data
28200 Disable/enable communications with slave No.1.
[Data type] Byte
[Data range] 0, 1
Sets whether to disable or enable communications with the slave No.1
node. Communications is started when this parameter is set to "1" and
the power is turned ON again.
This parameter is equivalent to the "1 DIS/ENB" setting in screen
1.2.2(a) or 1.2.1(c).
Setting Value Meaning
0 Disables communications.
1 Enables communications.
28201 MAC-ID of slave No.1
[Data type] Byte
[Data range] 0 to 63
Sets the number for identifying the slave to be connected.
Set a number that does not duplicate the MAC-ID of other nodes on
the network within the range 0 to 63.
(MAC-ID: Media Access Control ID)
This parameter is equivalent to the "2 MAC-ID" setting in screen
1.2.2(a) or 1.2.1(c).
