DeviceNet Board Operators manual Page 75

Operators manual
B-63404EN/03 OPERATION 1.DeviceNet FUNCTIONS
- 63 -
Parameters
28000 Enable/disable communications
[Data type] Byte
[Data range] 0, 1
Sets whether to disable or enable communications. Communications
is started when this parameter is set to "1" and the power is turned ON
again.
This parameter is equivalent to the "1 DIS/ENB" setting in screen
1.3(a) or 1.3(c).
Setting Value Meaning
0 Disables communications.
1 Enables communications.
28001 MAC-ID
[Data type] Byte
[Data range] 0 to 63
Sets the number for identifying on the master device the DeviceNet
interface board mounted on the control unit (CNC).
Set a number that does not duplicate the MAC-ID of other nodes on
the network within the range 0 to 63.
(MAC-ID: Media Access Control ID)
This parameter is equivalent to the "2 MAC-ID" setting in screen
1.3(a) or 1.3(c).
28002 Baud rate
[Data type] Byte
[Data range] 0 to 2
Sets the baud rate. Set the same value as the baud rate of the master
device as the setting value.
This parameter is equivalent to the "3 BAUD-RATE" setting in screen
1.3(a) or 1.3(c).
Setting Value Baud rate
0 125Kbps
1 250Kbps
2 500Kbps
28010 DI data buffer area
[Data type] Byte
[Data range] 0
Sets the area to be used as the DI data buffer. Use the R area as the
address to be set.
This parameter is equivalent to the buffer area setting in "4 DI
ADDRESS" in screen 1.3(a) or 1.3(c).
Setting Value Buffer Area
0 R area
