DeviceNet Board Operators manual Page 33

Operators manual
B-63404EN/03 OPERATION 1.DeviceNet FUNCTIONS
- 21 -
Table 1.2.1 (c): Relationship between STATUS SIZE setting values
and STATUS information
Setting
Value
Item Description
1 STATUS information This 1-byte data notifies the PMC of the
communications status.
00h : Disables communications.
01h : Enables communications. (normal
communications status)
03h : Communications error has
occurred.
For details, check the
COMMUNICATION STATUS and
status of the master device.
82h : Illegal MAC-ID
84h : Duplicate MAC-ID
8Eh : Bus error has occurred.
8?h : An error other than the above
occurred at start of
communications.
This 1-byte data indicates the
communications status with each node
having slave No. 1 to 8 in each of its
respective eight bits.
Bit #7 #6 #5 #4 #3 #2 #1 #0
Node 8 7 6 5 4 3 2 1
2 Slave communications
status 1
(slave No. 1 to 8)
Communications status (common to all
bits)
1: Enables communications. (normal
communications status)
0: Disables communications.
This 1-byte data indicates the
communications status with each node
having slave No. 9 to 16 in each of its
respective eight bits.
Bit #7 #6 #5 #4 #3 #2 #1 #0
Node 16 15 14 13 12 11 10 9
3 Slave communications
status 2
(slave No. 9 to 16)
Communications status (common to all
bits)
1: Enables communications. (normal
communications status)
0: Disables communications.
