Setting Slave Parameters on the Series 15i-A
In the slave parameter screen, specify slave parameters and address
assignment.
Screen 1.2.2 (c) Bus parameter setup screen (Series 15i-A)
Table 1.2.2(a) lists the parameters to be set up in this screen.
You can enter setting values in this screen provided that the following
conditions are satisfied:
<1> Bit 0 (PWE) of setting parameter No. 8000 = 1
<2> The unit is in the MDI mode or at an emergency stop.
<3> DISABLE is selected at "DISABLE/ENABLE."
Display procedures
Procedure 1
(1) Press function key
SYSTEM
repeatedly until the bus parameter
screen, slave parameter screen, or slave function setup screen is
displayed.
(2) If the bus parameter screen or slave function setup screen is
displayed, enter the desired slave number, and press soft key
[SLAVE PARAM].
Procedure 2
(1) Press function key
SYSTEM
or soft key [SYSTEM].
(2) Press soft key [CHAPTER] repeatedly until [DEVICENET] is
displayed.
(3) Press soft key [DEVICENET].
(4) If the bus parameter screen or slave function setup screen is
displayed, enter the desired slave number, and press soft key
[SLAVE PARAM].
