DeviceNet Board Operators manual Page 76

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 64 -
28011 DI data buffer address
[Data type] Word
[Data range] 0 to (value obtained by subtracting the setting value of No.28012 from
the maximum value of the R area)
Sets the area to be used as the DI data buffer. Set the leading address
of the buffer.
This parameter is equivalent to the buffer address setting in "4 DI
ADDRESS" in screen 1.3(a) or 1.3(c).
28012 DI data buffer size
[Data type] Byte
[Data range] 0 to 64
Sets the area to be used as the DI data buffer. Set the size of the buffer
within the range 0 to 64.
This parameter is equivalent to the "5 DI SIZE" setting in screen
1.3(a) or 1.3(c).
28013 DO data buffer area
[Data type] Byte
[Data range] 0
Sets the area to be used as the DO data buffer. Use the R area as the
address to be set.
This parameter is equivalent to the buffer area setting in "6 DO
ADDRESS" in screen 1.3(a) or 1.3(c).
Setting Value Buffer Area
0 R area
28014 DO data buffer address
[Data type] Word
[Data range] 0 to (value obtained by subtracting the setting value of No.28015 from
the maximum value of the R area)
Sets the area to be used as the DO data buffer. Set the leading address
of the buffer.
This parameter is equivalent to the buffer address setting in "6 DO
ADDRESS" in screen 1.3(a) or 1.3(c).
28015 DO data buffer size
[Data type] Byte
[Data range] 0 to 64
Sets the area to be used as the DO data buffer. Set the size of the
buffer within the range 0 to 64.
This parameter is equivalent to the "7 DO SIZE" setting in screen
1.3(a) or 1.3(c).
