Table 1.2.2 (b): Diagnostics information (STATUS/CONDITION)
Item Description
STATUS Displays the communications status.
DISABLE : Disables communications.
ENABLE : Enables communications.
ERROR : Communications error has
occurred.
For details, check CONDITION,
status of COMMUNICATION
STATUS in the bus parameter
screen, and the status of the
master function.
INVALID MAC ID : The MAC-ID is not set correctly.
DUPLICATE MAC ID : Duplicate MAC-IDs have been set.
DUPLICATE DEVICE : A MAC-ID duplicating the bus
parameter has been set.
INVALID CONNECTION : Connection by the correct I/O
Connection is not made.
The connection by these
DeviceNet master functions is Poll
I/O Connection.
POWER ON ERROR : An error occurred when the power
was turned ON or when ENABLE
was set.
Check the network cable
connections or DeviceNet interface
board mounting state.
CONDITION Displays the states of the connected slaves.
(00) DISABLE : Disables communications.
(01) IDLE : Network scan standby state
(02) DEVICE BEING SCANED : Normal communications
status
Scanning of connected
slaves is being performed
correctly.
(03) TIMED-OUT : Time-out state
There is no response from
the slaves.
(04) CONNECTION ERROR : The UCMM (Unconnected
Message Manager)
connection cannot be
performed correctly.
(05) CONNECTION BUSY : Master/Slave connection is
busy.
(06) CONNECTION ERROR : Master/Slave connection
cannot be established.
(07) INVALID VENDOR ID : The vendor ID of the
currently connected slave
differs from the parameter
setting value.
(08) VENDOR ID ERROR : The vendor ID of the
currently connected slave
cannot be read.
