DeviceNet Board Operators manual Page 40

Operators manual
1.DeviceNet FUNCTIONS OPERATION B-63404EN/03
- 28 -
Table 1.2.2 (a): Slave parameter setup items
Item Description
1 DIS/ENB
(DISABLE/ENABLE)
Sets whether to disable or enable communications
with the node having the selected slave No.
Move the left and right cursor keys to select this
parameter setting. (Soft keys are used in the 15i-
A.)
Set ENABLE after setting of the master function
parameters is completed.
Communications is started several seconds after
setting ENABLE.
DISABLE : Disables communications.
ENABLE : Enables communications.
2 MAC-ID Sets the number for identifying on the network the
slave to be connected.
Set a number that does not duplicate the MAC-ID
of other nodes on the network within the range 0 to
63.
(MAC-ID: Media Access Control ID)
3 VENDOR ID
4 DEVICE TYPE
5 PRODUCT CODE
Set the vendor ID/device type/product code of the
slave to be connected.
Set in hexadecimal within the range 0000 to FFFF.
(default: 0000)
These setting values are used for specifying the
type of connected type. If the setting value does
not match the value specific to the connected
slave, an error (INVALID VENDOR ID/INVALID
DEVICE TYPE/INVALID PRODUCT CODE)
occurs. Note, however, that this error is not
detected when the setting value is set to "0000".
Also, as nodes on the network are identified by a
MAC-ID, communications is performed normally
even if the setting value of these items is set to
"0000".
In a normal communications state, the values of
these items can be read from the connected slave
and the read values automatically set to the
respective items by operating soft key [INIT].
6 CONNECTION Sets the connection type with the slave.
"0" must be set.
Setting to "0" sets the connection type with the
slave to Poll I/O Connection.
7 DI ADDRESS
8 DI SIZE
9 DO ADDRESS
10 DO SIZE
Set the areas to be used as the DI/DO data buffer.
Set the leading buffer address and buffer size.
Use the R area as the address to be set.
Size setting range: 0 to 32
