DeviceNet Board Operators manual Page 51

Operators manual
B-63404EN/03 OPERATION 1.DeviceNet FUNCTIONS
- 39 -
Parameters
28100
Enable/disable communications
DI16
[Data type] Byte
[Data range] 0, 1
Sets whether to disable or enable communications. Communications
is started when this parameter is set to "1" and the power is turned ON
again.
This parameter is equivalent to the "1 DIS/ENB" setting in screen
1.2.1(a) or 1.2.1(b).
Setting Value Meaning
0 Disables communications.
1 Enables communications.
28101
MAC-ID
DI16
[Data type] Byte
[Data range] 0 to 63
Sets the number for identifying on the network the DeviceNet
interface board mounted on the control unit (CNC).
Set a number that does not duplicate the MAC-ID of other nodes on
the network within the range 0 to 63.
(MAC-ID: Media Access Control ID)
This parameter is equivalent to the "2 MAC-ID" setting in screen
1.2.1(a) or 1.2.1(b).
28102
Baud rate
DI16
[Data type] Byte
[Data range] 0 to 2
Sets the baud rate. The baud rate is limited by the maximum network
length and other factors. For details, see the "Connecting the
DeviceNet Functions" item in the Connections section.
This parameter is equivalent to the "3 BAUD-RATE" setting in screen
1.2.1(a) or 1.2.1(b).
Setting Value Baud rate
0 125Kbps
1 250Kbps
2 500Kbps
28116 Status information data buffer area
[Data type] Byte
[Data range] 0
Sets the area to be used as the status information data buffer. Use the
R area as the address to be set.
This parameter is equivalent to the buffer area setting in "4 STATUS
ADDRESS" in screen 1.2.1(a) or 1.2.1(b).
Setting Value Buffer Area
0 R area
