Open CNC (Ladder Editing Package) Operators manual Page 55

Operators manual
3. OPERATION
B–62884EN/01
50
(d) Searching for data (F8 [SEARCH])/Entering the search data (
Shift
+
F8
)
1) Searching for data (F8 [SEARCH])
A search for a net starts when the
F8
key is pressed after the
search data has been entered.
If the
F8
key is pressed without specifying any search data, a
search is made for the data set specified in 2) below, ”Entering
search data” (see (b)).
A search can be made for several types of data, as described
below:
D Address/symbol
Searching for an address: “address” +
F8
Example) “X0000.0”+
F8
Searching for a symbol: “symbol” +
F8
Example) “SYMBOL1”+
F8
D Functional instruction number/name
Searching for a number: “S”+“functional–
instruction–number”+
F8
Example) “S1”+
F8
Searching for a name: “functional–instruction–
name” +
F8
Example) “END1”+
F8
D Net number: “net–number”+
F8
Example) “10”+
F8
2) Entering search data (
Shift
+
F8
)
Data for which a search is to be made by means of operation 1),
described above, can be registered. To repeatedly search for
identical data, use this function. While this function is active, the
following dialog box appears.
To position the cursor to another item, press the
Tab
key. To
change the setting, press the
or key.
Previous page
Next page
