Open CNC (Ladder Editing Package) Operators manual Page 61

Operators manual
3. OPERATION
B–62884EN/01
56
On–line editing operations (2)
Operation
group
Function Key to be used Reference
Cursor
movement
Moving the cursor up or
down
,
(h) 1)
Moving the cursor to the
left or right
,
(h) 2)
Moving the cursor to the
beginning of the ladder
program
Home
(h) 3)
Moving the cursor to the
end of the ladder
program
End
(h) 4)
Moving the cursor to the
previous page
Page
Up
(h) 5)
Moving the cursor to the
next page
Page
Down
(h) 6)
Search Searching for data F8 : [Search] See (1),
“Ladder
Entering the search data
+
F8
Shift
“L
a
dd
er
monitor.”
Symbol Displaying the symbol or
comment defined at a
specified address
F9 : [Symbol] See (1),
“Ladder
monitor.”
Setting Switching between
ladder monitor and
on–line editing, switching
between symbol display
and comment display,
etc.
F10 :[Setting] See (1),
“Ladder
monitor.”
Others Updating the ladder
program
F7 : [UPDATE] (i) 1)
Restoring the ladder
program to the state
existing prior to editing
+
Shift
F7
(i) 2)
(c) Changing the input mode
To change the input mode on the edit screen, use the following keys.
The current input mode is displayed at the bottom right corner of the
screen. When nothing is displayed, it indicates that overwrite mode
is selected (default).
1) Insert mode
Key :
Insert
Function : When a contact or coil is entered in this mode,the
contact or coil is inserted at the cursor position.
Cancel : Press the
Insert
key in insert mode.
2) Delete mode
Key :
Delete
Function : When the line connect function is used in this
mode,data at the cursor position is deleted.
